| | Features |  | - Supports DDR4 Memory, Dual Channel DDR4 4800+MHz (OC)
- Core Boost : With premium layout and digital power design to support more cores and provide better performance
- Memory Boost: Advanced technology to deliver pure data signals for the best performance, stability and compatibility
- Lightning Fast Experience: PCIe 4.0, Lightning Gen4 x4 M.2 with M.2 Shield Frozr
- AUDIO BOOST: Reward your ears with studio grade sound quality for the most immersive gaming experience
- Steel Armor: Protecting VGA cards against bending and EMI for better performance, stability and strength
| |
| | Specifications |  | | CHIPSET | | INTEL B760 | | CPU | | Support Intel Core 14th/ 13th/ 12th Gen Processors | | MEMORY | | 4x DDR4,4800(OC)-2133 MHz,4x DDR4, Maximum Memory Capacity 128GB | | ONBOARD GRAPHICS | | 1x HDMI,1x DisplayPort,1x VGA | | SLOT | | 6x PCI-E | | STORAGE | | 2x M.2,4x SATA 6G | | RAID | | Yes | | USB | | 12 | | LAN | | Realtek RTL8111H Gigabit LAN | | AUDIO | | Realtek ALC897 Codec | | LED FEATURE | | 4x EZ Debug LED | | OPERATING SYSTEM | | Support for Windows 11 64-bit, Windows 10 64-bit | | PCB INFO | | mATX | | | | |
| |
|
