| Audio Performance | | Output Signal-to-Noise Ratio (A-Weighted) (Front-out) : |
| 118 dB | | |
| Output Signal-to-Noise Ratio (A-Weighted) (Headphone-out) : | | |
| 110 dB | | |
| Input Signal-to-Noise Ratio (A-Weighted) : | | |
| Output THD+N at 1kHz (Front-out) : | | |
| 0.00039 %(-108 dB) | | |
| Output THD+N at 1kHz (Headphone-out) : | | |
| 0.001 %(300 dB) | | |
| Input THD+N at 1kHz : | | |
| 0.0003 %(-110 dB) | | |
| Frequency Response (-3dB, 24bit/96KHz input) : | | |
| 10 Hz to 48 KHz | | |
| Output/Input Full-Scale Voltage : | | |
| Unbalanced Output : 2.2 Vrms (3 Vp-p) | | |
| Headphone : 7 Vrms (9.9 Vp-p) | | |
| Bus Compatibility | | PCI Express |
| Chipset | | Audio Processor :C-Media CMI8888DHT High-Definition Sound Processor (Max. 96KHz/24bit) |
| Sample Rate and Resolution | | Analog Playback Sample Rate and Resolution : |
| 44.1K/48K/88.2K/96K/176.4K/192KHz @ 16bit/24bit | | |
| Analog Recording Sample Rate and Resolution : | | |
| S/PDIF Digital Output : | | |
| S/PDIF Digital Input : | | |
| ASIO 2.2 Driver Support : | | |
| 44.1K/48K/88.2K/96K/176.4K/192KHz @ 16bit/24bit with very low latency | | |
| I/O Ports | | Analog Output Jack : |
| 5 x 3.5mm RCA jack | | |
| Analog Input Jack : | | |
| 2 x 3.5mm RCA jack | | |
| 1 x Digital S/PDIF Output : 1 x Toslink | | |
| 1 x Box link | | |
| Other line-level analog input (for CD-IN/TV Tuner) : 4-pin header on the card | | |
| Special Features | | Dolby? Technologies : Dolby? Home Theater v4 |
| Smart Volume Normalizer? | | |
| Xear Surround? | | |
| Magic Voice? | | |
| FlexBass? | | |
| GX 3.0 Game Audio Engine | | |
| Accessories | | Control box x 1 |
| Driver CD x 1 | | |
| Quick Start Guide x 1 | | |
| S/PDIF adaptor x 1 | | |
| ATX 4P-to-6P power cable x 1 | | |
| | | |
